APC E3SUPS30K3IB UPS Dubbele conversie (online) 30 kVA 30000 W

APC E3SUPS30K3IB, Dubbele conversie (online), 30 kVA, 30000 W, 304 V, 477 V, 45/65 Hz

Niet op voorraad

Fabrikant APC
MPN E3SUPS30K3IB
EAN 0731304340805
€ 6.919,00 excl. BTW

APC E3SUPS30K3IB UPS Dubbele conversie (online) 30 kVA 30000 W

High-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy to install, operate, maintain, and service 30 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is for internal batteries, but is supplied without batteries, so you can easily customize the battery runtime. For battery runtime details, see the runtime charts published under the Documents tab.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

UPS-topologie*
Dubbele conversie (online)
Output power capacity*
30 kVA
Uitgangsvermogen*
30000 W
Ingang operation voltage (min)*
304 V
Ingang operation voltage (max)*
477 V
Frequentie*
45/65 Hz
Uitgang operation voltage (min)
220 V
Uitgang operation voltage (max)
240 V
Output frequentie
50/60 Hz
Stroom (max.)
55 A
Input vermogensfactor
0,99
Crest factor
3:1
Output voltage THD
1,5 procent
Input stroom THD
5 procent
Geluidsniveau
63 dB

Accu/Batterij

Batterijtechnologie
Sealed Lead Acid (VRLA)
Accu/Batterij voltage
240 V
Ondersteund aantal accu's/batterijen
4

Design

Vormfactor*
Tower
Kleur van het product*
Wit

Design

Internationale veiligheidscode (IP)
IP20
Certificering
REACH, CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-15 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 95 procent
Luchtvochtigheid bij opslag
0 - 95 procent
Hoogte, in bedrijf
0 - 984,3 m
Hoogte bij opslag
0 - 15000 m

Technische details

Duurzaamheidscertificaten
RoHS

Gewicht en omvang

Breedte
500 mm
Diepte
996 mm
Hoogte
1400 mm
Breedte verpakking
683 mm
Diepte verpakking
1114 mm
Hoogte verpakking
1640 mm
Gewicht verpakking
185 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85078000
