APC SMTL1500RM3UC UPS Line-interactive 1,5 kVA 1350 W 6 AC-uitgang(en)

APC SMTL1500RM3UC, Line-interactive, 1,5 kVA, 1350 W, Sinus, 75 V, 154 V

Nog 1 beschikbaar (bel voor reservering)

Fabrikant APC
MPN SMTL1500RM3UC
EAN 0731304339632
€ 1.793,00
€ 1.687,00 excl. BTW

APC SMTL1500RM3UC UPS Line-interactive 1,5 kVA 1350 W 6 AC-uitgang(en)

APC is the industry leader in network and server UPSs

Smart-UPS with lithium-ion batteries saves up to 47% in Total Cost of Ownership (TCO) over the lifetime of the UPS. Battery life is increased 2X. Reduced maintenance cost and improved battery performance in temperatures up to 104°F. UPS management options include Powerchute Business Edition, APC SmartConnect, Network Management Cards and EcoStruxure IT. The additional benefit of a 12-inch short-depth chassis allows this UPS to be installed in any 4-post rack and most wall-mount racks. The APC Smart-UPS Lithium-ion (Li-ion) UPS provides pure sine wave output power protection for servers, voice/data networks, medical labs and light industrial applications. As one of the world’s largest and most respected power protection designers and manufacturers, APC is relied upon daily for power protection and availability. APC products offer the maximum level of protection, safety, convenience, and reliability. Everything you love about Smart-UPS now with lithium-ion batteries!

APC is the industry leader in network and server UPS

- Lithium-Ion battery provides twice the services life of the lead-acid batteries typically used in (Uninterruptible Power Supplies) UPS
- Intelligent battery management system Li-ion batteries are monitored at an individual cell level to manage voltage and temperatures of the set of cells. This helps the Li-ion batteries to provide a higher level of safety.
- High-efficiency green mode Achieves up to 97% percent efficiency, which minimizes utility and cooling costs without compromising performance or reliability.

Smart-UPS SMTL1500RM3UC

- Alphanumeric LCD Display Intuitive interface provides detailed and accurate information with ability to configure locally-function LCD display
- Built-in energy meter Measures energy use and displays UPS efficiency in various modes of operation for easy energy tracking.
- Flash upgradeable firmware Allows for field updates of firmware via communication ports or Network Management Card (NMC)

Smart-UPS SMTL1500RM3UC

Switchable outlet group Ability to control a group of output load receptacles independent from the main UPS. Enables:
- Cycling the entire UPS
- Sequenced turn ON/OFF
- Shedding of noncritical loads based on a variety of parameters (battery time, runtime remaining, and overload)
- Scheduled time OFF to conserve energy
- Rebooting hung device without

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

UPS-topologie*
Line-interactive
Output power capacity*
1,5 kVA
Uitgangsvermogen*
1350 W
Golfvorm*
Sinus
Ingang operation voltage (min)*
75 V
Ingang operation voltage (max)*
154 V
Frequentie*
50/60 Hz
Uitgang operation voltage (min)
110 V
Uitgang operation voltage (max)
127 V
Output frequentie
50/60 Hz
Automatic Voltage Regulation (AVR)
Ja
Surge energy rating
680 J
Output voltage THD
5 procent
Geluidsniveau
45 dB
Geluidsalarm(en)
Ja
Hoorbare alarmstanden
Alarm bij werking op batterij, Alarm bij laag batterijniveau, Alarm bij overbelasting
Auto-herstart
Ja
Temperatuurspanningscompensatie
Ja

Poorten & interfaces

Stopcontacttypes
NEMA 5-15R
Stekker
NEMA 5-15P
Aantal AC uitgangen
6 AC-uitgang(en)
USB-poort
Ja
Seriële interface
Ja
SmartSlot
Ja

Accu/Batterij

Batterijtechnologie
Lithium-Ion (Li-Ion)
Acculevensduur (max)
10 jaar
Accu/Batterij oplaadtijd
2,5 uur
Hot-swap batterij
Ja
Automatische batterij test
Ja
Koude start
Ja

Design

Vormfactor*
Rackmontage

Design

Rackcapaciteit
3U
Snoerlengte
2,44 m
Kleur van het product*
Zwart, Zilver
Type beeldscherm
LCD
LED-indicatoren
Ja
Internationale veiligheidscode (IP)
IP20
Certificering
CSA C22.2 No. 107.1, FCC Part 15 Class A, NOM, UL 1778

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 35 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 95 procent
Luchtvochtigheid bij opslag
0 - 95 procent
Hoogte, in bedrijf
0 - 3000 m
Hoogte bij opslag
0 - 7500 m

Technische details

Duurzaamheidscertificaten
RoHS

Gewicht en omvang

Breedte
438 mm
Diepte
302 mm
Hoogte
131 mm
Gewicht
19,5 kg
Breedte verpakking
584 mm
Diepte verpakking
448 mm
Hoogte verpakking
279 mm
Gewicht verpakking
22,9 kg

Verpakking

Zaaghouder
Ja
Meegeleverde kabels
RS-232, USB-kabel
Ondersteunings-cd
Ja
Software-cd
Ja

Logistieke gegevens

Producten per pallet
12 stuk(s)
Code geharmoniseerd systeem (HS)
85078000
