Asustor AS3104T NAS Ethernet LAN Zwart N3050

Asustor AS3104T, NAS, Intel® Celeron®, N3050, Zwart

Niet op voorraad

Fabrikant ASUS
MPN 90IX00P1-BW3S10
EAN 4710474830749
€ 330,00 excl. BTW

Asustor AS3104T NAS Ethernet LAN Zwart N3050

Powered by the latest Intel Celeron processors
AS3104 is powered by Intel Celeron Braswell dual-core processors, equipped with 2GB of dual-channel memory, and feature read speeds of over112 MB/s and write speeds of over 112 MB/s under RAID 5 configurations.

Dual-channel power
The AS31 models support dual-channel memory, be able to smoothly playback 4K video. Furthermore, AS31 series devices are not only energy efficient, but offer a combination of performance and price that is unmatched in its class. Get ready to enjoy brilliant ultra high-definition 4K video from the comfort of your own home!

Supercharge your multimedia experience
You no longer need to worry about running into resolution compatibility issues when playing videos on your phone, tablet or computer.
Media Converter utilizes a quick and simple conversion method, allowing you to execute conversion tasks in the background.
The exclusive built-in Hyper-Transcoding technology was expertly crafted by ASUSTOR. This technology utilizes the Intel CPU hardware acceleration function to make video file conversions faster and simpler than ever before. Using Hyper-Transcoding to convert video files can reduce the normal conversion time by at least 10 times.

Toolless installation
The AS31 series’ sliding outer cover design allows it to be conveniently removed when needed. The inner hard disk rails and outer cover all use hand screws allowing for the simple installation of hard disks without any extra tools.

Add modern flair to your favorite space
The AS31 series devices redefine the aesthetics of a NAS. The stylish diamond-plate finished cover makes it an elegant addition to any space, no matter if it is a family room, living room or office.

Hardware encryption engine
Protecting your data is ASUSTOR’s top priority. The AS31 series devices feature Intel AES-NI encryption engines, allowing data to be completely protected from the moment it is first stored on the NAS. This means that you never have to worry about your confidential data falling into the wrong hands even if your hard disks become lost or stolen. The built-in hardware encryption engine also features read speeds of over 112 MB/s and write speeds of over 71 MB/s for encrypted data providing an optimal combination of file security and system performance.

High capacity cloud storage for all your digital assets
The AS3104 provides a large capacity NAS for home users at an affordable price. Users can install four 8 TB hard disks to immediately create a high capacity storage space of up to 32 TB. When taking photos or recording videos of family vacations, gatherings and other cherished memories, users no longer need to be confined to the limited storage on memory cards. With high capacity AS3104, users can save all of their videos and photos in high quality resolution, preserving them perfectly. Additionally, RAID 5 and 6 storage volume setting provide comprehensive protection for all digital assets stored on the NAS, minimizing the risk of data loss due to hard disk failure or accidents.

Create the Ultimate Home Multimedia Center
Enjoy electrifying digital entertainment on demand with ASUSTOR NAS. The built-in HDMI interface and variety of multimedia Apps let you to enjoy all of your favorite multimedia from your NAS by directly connecting it to an LCD/LED TV or amplifier.

ASUSTOR NAS supports Full HD (1080p) output, allowing you to savor your movies, TV shows, music and photos in high definition. What's more, through ASUSTOR's App Central, you can install additional multimedia server Apps such as UPnP Media Server and iTunes Server giving your NAS the ability to stream multimedia content to your computers, TVs and mobile devices.

Additionally, you can also further add a surround sound amplifier to create an unprecedented high definition multi-channel listening experience. Imagine watching your favorite racing movie and being immersed in the roar of the engines. Feel the thrill and the sense of speed as you listen to the sounds of cars whizzing by. Prepare for an unparalleled entertainment experience that will have you on the edge of your seat.

Even More Reliable After-Sales Service
ASUSTOR has extended the warranty period on all of its products to three years, continuing to make customer service a huge priority. It is ASUSTOR's mission to continue to provide its customers with products of the highest quality along with only the most reliable and attentive after-sales service and technical support.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Opslagmedia

Opslag schijf-interface*
SATA II, SATA III
Opslag schijfgrootte
3.5"
Maximaal ondersteunde opslagcapaciteit
32 TB
RAID support*
Ja
Soorten RAID
0, 1, 5, 6, 10, JBOD
Hot-swap drive bays
Ja
Ondersteunde bestandsystemen
FAT32, HPFS, NTFS, ext3, ext4
Opslagdrives geïnstalleerd*
Nee
Aantal storage drives ondersteund*
4
Geïnstalleerde opslag-drive*
Nee
Ondersteunde types opslag-drives*
HDD

Processor

Processorfabrikant*
Intel
Processorfamilie*
Intel® Celeron®
Processormodel*
N3050
Frequentie van processor*
1,6 GHz
Maximale turbofrequentie van processor
2,16 GHz
Aantal processorkernen
2
Processor aantal threads
2
Processor cache
2 MB
CPU configuratie (max)
1
ECC ondersteund door processor
Nee
Geïntegreerde 4G WiMAX
Nee
PCI Express slots versie
2.0
Processor cache type
L2
Codenaam processor
Braswell
Processor lithografie
14 nm
Processor operating modes
64-bit
Verpakkingsgrootte processor
25 x 27 mm
Processorserie
Intel Celeron N3000 series
Processor socket
BGA 1170
Scenario Design Power (SDP)
4 W
Stepping
C0
Systeembus
5 GT/s
Tjunction
90 °C
Thermal Design Power (TDP)
6 W
On-board graphics adapter model
Intel® HD Graphics
Maximaal intern geheugen ondersteund door processor
8 GB
Conflictvrije processor
Ja

Geheugen

Intern geheugentype
DDR3L
Kloksnelheid geheugen
1600 MHz
Intern geheugen*
2 GB

Netwerk

Ethernet LAN*
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Wifi
Nee
DHCP client
Ja
Jumbo Frames ondersteuning
Ja
iSCSI support
Ja
Wake-on-LAN
Ja
Ondersteunde netwerkprotocollen
CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS, Proxy, SNMP, Syslog

Poorten & interfaces

Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A
3
Aantal HDMI-poorten
1
Aantal Ethernet LAN (RJ-45)-poorten*
1

Grafisch

Basisfrequentie ingebouwde grafische adapter
320 MHz
On-board grafische adapter burst frequentie
600 MHz
Maximaal geheugen ingebouwde grafische adapter
8 GB
Aantal displays ondersteund (door on-board grafische adapter)
3

Design

Type koeling*
Actief
Kleur van het product
Zwart
Aantal ventilatoren
1 ventilator(en)
Ventilator diameter
12 cm

Prestatie

Soort*
NAS
Apparaatklasse*
Home & Home Office
Backup-functie*
Ja
Back-up-eigenschappen
Cloud
Ondersteunt meerdere talen
Ja

Prestatie

Geluidsniveau (buiten gebruik)
19,7 dB
Ondersteunde beveiligingsalgoritmen
HTTPS, SSH, SSL/TLS

Software

Inclusief besturingssysteem*
ADM
Operating systeem versie
2,6
Ondersteunt Windows
Ja
Ondersteunt Linux
Ja
Ondersteunt Mac-besturingssysteem
Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Ondersteunde server operating systems
Windows Server 2003, Windows Server 2008, Windows Server 2012

Energie

Stroomverbruik (typisch)
24,5 W
Slaapstand
0,69 W

Gewicht en omvang

Breedte*
164 mm
Diepte*
218 mm
Hoogte*
165 mm
Gewicht
1,6 kg

Processor speciale functies

Ingebouwde opties beschikbaar
Nee
Enhanced Intel SpeedStep Technology
Ja
Execute Disable Bit
Ja
Idle States
Ja
Intel® 64
Ja
Intel® Clear Video-technologie
Ja
Intel® Enhanced Halt State
Ja
Versie Intel® Identity Protection Technology
1,00
Intel® Rapid Storage Technology
Nee
Intel® Veilig opstarten
Ja
Versie Intel® Secure Boot Technology
1,00
Versie Intel® Secure Key Technology
1,00
Intel® Small Business Advantage (SBA)-versie
0,00
Intel® Smart Connect Technology
Nee
Versie Intel® Smart Connect Technology
0,00
Versie Intel® Smart Response Technology
0,00
Intel® Stable Image Platform Program (SIPP)
Nee
Versie Intel® Stable Image Platform Program (SIPP)
0,00
Intel® Trusted Execution Technology
Nee
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Nee
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Anti-Theft Technology (Intel® AT)
Nee
Intel® Clear Video HD Technology (Intel® CVT HD)
Ja
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID)
Ja
Intel® High Definition Audio (Intel® HD Audio)
Ja
Intel® Hyper Threading Technology (Intel® HT Technology)
Nee
Intel® Identity Protection Technology (Intel® IPT)
Ja
Intel® Insider™
Nee
Intel® InTru™ 3D Technology
Nee
Intel® OS Guard
Nee
Intel® Quick Sync Video Technology
Ja
Intel® Secure Key
Ja
Intel® Small Business Advantage (Intel® SBA)
Nee
Intel® Smart Response Technology
Nee
Intel® Turbo Boost Technology
Nee
Intel® Wireless Display (Intel® WiDi)
Ja
Maximaal aantal PCI Express-lijnen
4
Aantal verwerkingseenheden
12
Thermal Monitoring Technologies
Ja
UART
Ja
Geheugenkanalen ondersteund door processor
Dual
Geheugentypen ondersteund door processor
DDR3L-SDRAM

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
5 - 35 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent

Certificaten

Certificering
FCC, CE, VCCI, BSMI, C-TICK

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84714100

Overige specificaties

ARK ID processor
87257
