Datalogic Gryphon I GBT4500 Draagbare streepjescodelezer 1D/2D Laser Zwart

Datalogic Gryphon I GBT4500, Draagbare streepjescodelezer, 1D/2D, Laser, Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, PDF417, U.P.C., Aztec Code, Datamatrix, GS1 DataBar Expanded Stacked, GS1 DataBar Gestapeld Omnidirectioneel,..., 1280 x 800 Pixels

Ruim op voorraad

Fabrikant Datalogic
MPN GBT4500-BK-HD-WLC
EAN 5706998664839
€ 369,00 excl. BTW

Datalogic Gryphon I GBT4500 Draagbare streepjescodelezer 1D/2D Laser Zwart

The Gryphon 4500 series stands out with an elegant and trendy design, user friendly ergonomics and features the most advanced megapixel sensor with warm-white-illumination 2D technology for outstanding performance.

The Gryphon 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes. High Density (HD) models are available for reading smaller, condensed codes as well as a dedicated version with red illumination optics to support Digital Watermarking.

Datalogic’s Motionix™ motion-sensing technology enables the scanner to intuitively switch into ‘hand held’ mode when the device is picked up. When placed back into the cradle, it seamlessly returns to ‘stand’ mode. The adjustable position cradle provides the flexibility to use the scanner in presentation or stand mode while it is charging.

The wireless models feature Bluetooth wireless technology (GBT model) or narrow band radio communications with Datalogic’s STAR Cordless System (GM model).

One of the most important technical innovations that the Gryphon 4500 wireless readers achieve is the wireless charging system for the battery, which enhances the reliability of the entire solution, while lowering the total cost of ownership (no need for contact cleaning or maintenance procedures). The maximum reliability offered by the Gryphon wireless charging technology means 24/7 activities with no stops for maintenance or repair and top-level operating productivity and performance.

The Gryphon 4500 imagers are also available in Healthcare models featuring disinfectant-ready and anti-microbial enclosures for applications in the Healthcare industry.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Scannen

Soort*
Draagbare streepjescodelezer
Soort scanner*
1D/2D
Type beeldsensor*
Laser
Ondersteunde streepjescodes (1D)*
Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, PDF417, U.P.C.
2D ( matrix en gestapeld ) barcodes ondersteund*
Aztec Code, Datamatrix, GS1 DataBar Expanded Stacked, GS1 DataBar Gestapeld Omnidirectioneel, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Resolutie optische sensor (WxH)
1280 x 800 Pixels
Licht niveaus (direct zonlicht)
0 - 100000 Lux
Golflengte
650 nm
Tilt lees-hoek
0 - 360°
Pitch lees-hoek
-65 - 65°
Yaw lees-hoek
-65 - 65°

Poorten & interfaces

Connectiviteitstechnologie*
Draadloos
Standaard interfaces*
Bluetooth
Aansluitbereik
100 m
Bluetooth-versie
4.0
Frequentie
2400 MHz

Prestatie

Internationale veiligheidscode (IP)
IP52
Kleur van het product*
Zwart

Energie

Type stroombron*
Batterij/Accu
Batterijtechnologie
Lithium-Ion (Li-Ion)
Capaciteit van de accu/batterij
3250 mAh
Accu/Batterij voltage
12 V
Aantal lezingen per inzet
80000
Oplaadtijd
4 uur
Ingangsspanning
4.5 - 14 V

Gewicht en omvang

Breedte
109 mm
Diepte
68 mm
Hoogte
166 mm
Gewicht*
235 g

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 50 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 95 procent

Technische details

Duurzaamheidscertificaten
RoHS

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84716070
