Datalogic HD3430-WHK1S barcode-lezer Draagbare streepjescodelezer 1D/2D CMOS Wit

Datalogic HD3430-WHK1S, Draagbare streepjescodelezer, 1D/2D, CMOS, GS1-128 (UCC/EAN-128), Aztec Code, Datamatrix, Han Xin, MaxiCode, Micro QR Code, QR Code, 0 - 100000 Lux

Ruim op voorraad

Fabrikant Datalogic
MPN HD3430-WHK1S
EAN 5704174103240
€ 244,00 excl. BTW

Datalogic HD3430-WHK1S barcode-lezer Draagbare streepjescodelezer 1D/2D CMOS Wit

OVERVIEW

Datalogic is pleased to announce the release of the Heron HD3430 2D area imager with unmatched elegance and advanced technology for the modern point-of-sale.
The Heron HD3430 2D imager provides a stunning black ‘carbon-fiber’ look or a white ‘silver’ color option, emphasizing the curving lines of the Heron’s enclosure. The imager also offers opportunities to incorporate a company brand identity by allowing customers to compose the perfect blend: combining a company logo with the top cover color with customized visual and audio feedback in order to reinforce the value of the customer’s brand.

FEATURES

Outstanding reading performance on 1D, 2D, postal codes, stacked, composite codes and Image capture
Multiple changing color LEDs on sides and top
Top of the market illumination and aiming system
Polyphonic speaker for a wide variety of choices regarding audio feedback
Datalogic’s patented ‘Green Spot’ technology for good-read feedback
Automatic switching between handheld and hands-free operations

APPLICATIONS

Non-food specialty stores such as Fashion Clothes, Cosmetics, Jewelry, Perfume, etc.
Duty-free and Airport stores
Commercial Services: Banks, Insurance Companies and Utilities
The Heron HD3430 2D area imager completes the Heron family offering by adding 2D reading capability to the existing Heron readers and providing customers with an unmatched choice regarding price and bar code reading needs.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Scannen

Soort*
Draagbare streepjescodelezer
Soort scanner*
1D/2D
Type beeldsensor*
CMOS
Ondersteunde streepjescodes (1D)*
GS1-128 (UCC/EAN-128)
2D ( matrix en gestapeld ) barcodes ondersteund*
Aztec Code, Datamatrix, Han Xin, MaxiCode, Micro QR Code, QR Code
Licht niveaus (direct zonlicht)
0 - 100000 Lux
Tilt lees-hoek
0 - 360°
Pitch lees-hoek
-65 - 65°
Yaw lees-hoek
-60 - 60°

Poorten & interfaces

Connectiviteitstechnologie*
Bedraad
Standaard interfaces*
USB, RS-232
USB-versie
2.0

Prestatie

LED-indicatoren
Ja
Kleur van het product*
Wit
Programmeringsfunctie
Ja

Energie

Type stroombron*
Batterij/Accu

Energie

Ingangsspanning
5 V
Stroomverbruik
500 mA

Gewicht en omvang

Breedte
68 mm
Diepte
153 mm
Hoogte
152 mm
Gewicht*
150 g

Verpakking

Meegeleverde kabels
USB

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 50 °C
Temperatuur bij opslag
-20 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 90 procent

Technische details

Duurzaamheidscertificaten
RoHS

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84716070
