Digitus DN-81004 netwerk transceiver module 1250 Mbit/s mini-GBIC 1310 nm

Digitus DN-81004, 1250 Mbit/s, mini-GBIC, LC, LX, TX, 20000 m, 1310 nm

Ruim op voorraad

Fabrikant Digitus
MPN DN-81004
EAN 4016032305729
€ 25,00 excl. BTW

Digitus DN-81004 netwerk transceiver module 1250 Mbit/s mini-GBIC 1310 nm

The plug and play fiber connection

- The Plug & Play fiber optic link enables quick installation
- Sends data in high quality and additionally provides excellent reliability
- Distance up to 20 km at a maximum data rate of 1.25Gbps
- Operating temperature: 0 °C ~ 70 °C

The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers.
  • Mini GBIC SFP (Small Form Factor Pluggable) module
  • Compatible with the following manuafacturers: Ubiquiti, Allied Telesis, Allnet, CISCO, D-Link, Edimax, Intellinet, KTI Networks, Level One, PLANET, Tenda, TP-Link, TRENDnet, ZyXEL, ZTE , Avaya , Mikrotik , ENTERASYS, FINISAR, FORCE 10 ,RIVERSTONE , Fortinet
  • Bidirectional WDM Module - Only one fiber is needed
  • High quality and excellent reliability
  • 1.25 Gbps Maximum Data Rate
  • Compliant to IEEE 802.3z Gigabit Standard
  • Class 1 laser product compliant with EN 60825-1
  • Easy plug-and-play installation
  • MSA (Multi Source Agreement) compliant
  • Hot pluggable
  • Connector: 1x LC Simplex
  • Wavelength: Tx 1550nm / Rx 1310nm
  • Transmission Power: Minimum -5 dBm, Maximum 0 dBm
  • Sensitivity receiving power: minimum -24 dBm
  • For a Distance of up to 20km
  • Suitable for 09/125µm Singlemode Fiber Cables
  • Safe fast-locking mechanism
  • 3.3V power supply
  • Operating temperature: 0 °C ~ 70 °C

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Prestatie

Maximale overdrachtssnelheid van gegevens*
1250 Mbit/s
Soort aansluiting*
mini-GBIC
Single-mode glasvezelkabel (SMF) ondersteund
Ja
Vezel-optische connector
LC
SFP-zendernorm
LX, TX
Maximaal bereik
20000 m
Golflengte
1310 nm
Tx-golflengte (max)
1550 nm
Rx-golflengte (max)
1310 nm
Ethernet interface type
Gigabit Ethernet
Netwerkstandaard
IEEE 802.3z
Digital Diagnostics Monitoring (DDM)
Nee

Kenmerken

Plug and play
Ja
Land van herkomst
China
Merkcompatibiliteit
MSA Compliant

Verpakking

Breedte verpakking
115 mm
Diepte verpakking
90 mm
Verpakkingsvolume
310,5 cm³
Gewicht verpakking
35,417 g

Logistieke gegevens

Code UK-handelstarief
85176200
Code geharmoniseerd systeem (HS)
85369010
