Digitus DN-81005-01 netwerk transceiver module Koper 1250 Mbit/s SFP

Digitus DN-81005-01, Koper, 1250 Mbit/s, SFP, 100 m, Gigabit Ethernet, China

Nog 19 beschikbaar

Fabrikant Digitus
MPN DN-81005-01
EAN 4016032454915
€ 34,00 excl. BTW

Digitus DN-81005-01 netwerk transceiver module Koper 1250 Mbit/s SFP

The plug and play extension for your network switch

- Extend your network switch with free SFP ports around additional RJ-45 connections
- Compatible with the popular network switch manufacturers
- Hot pluggable - installation possible while in operation
- Operating temperature: 0 °C ~ 70 °C

The DIGITUS® Mini GBIC (SFP) transceiver modules offer the highest quality and reliability. The module offers a perfect opportunity for you to extend your Gigabit network switch with a free SFP Uplink Port around an additional RJ45 connection. Thanks to the hot-plug capability, you can install the module without any interruption to the network traffic or restart of the device. In addition, conformity with the MSA (Multi Source Agreement) standard provides compatibility with the current network switch manufacturers.
  • Mini GBIC SFP (Small Form Factor Pluggable) module
  • Compatible with the following manuafacturers: Allied Telesis, Allnet, Avaya, CISCO, D-Link, Edimax, FINISAR, FORCE 10, Gigamon Intellinet, KTI Networks, Level One, PLANET, Tenda, TP-Link, TRENDnet, Mikrotik , ENTERASYS, RIVERSTONE , Unifi, Ubiquiti, ZyXEL, ZTE
  • Up to 1.25 Gbps bidirectional maximum data rate
  • Compliant to IEEE 802.3z Gigabit Standard
  • High quality and excellent reliability
  • Easy plug-and-play installation
  • MSA (Multi Source Agreement) compliant
  • Hot pluggable - installation possible while in operation
  • Auto MDI/MDI-X
  • Connection: 1x RJ45, CAT 5
  • Distance: up to 100 m
  • Operating temperature: 0 °C ~ 70 °C

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Prestatie

SFP transceiver type*
Koper
Maximale overdrachtssnelheid van gegevens*
1250 Mbit/s
Soort aansluiting*
SFP
Maximaal bereik
100 m
Ethernet interface type
Gigabit Ethernet
Auto MDI/MDI-X
Ja
Digital Diagnostics Monitoring (DDM)
Nee

Kenmerken

Plug and play
Ja
Hot-plug ondersteuning
Ja
Land van herkomst
China
Merkcompatibiliteit
MSA Compliant

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 70 °C

Verpakking

Aantal producten inbegrepen
1 stuk(s)
Breedte verpakking
93 mm
Diepte verpakking
32 mm
Verpakkingsvolume
357,12 cm³
Gewicht verpakking
58,333 g

Logistieke gegevens

Code UK-handelstarief
85176200
Code geharmoniseerd systeem (HS)
85369010
