Digitus DN-95108 PoE adapter & injector 10 Gigabit Ethernet 52 V

Digitus DN-95108, 10 Gigabit Ethernet, 10,100,1000,2500,5000,10000 Mbit/s, IEEE 802.3at, Zwart, 100 m, Power over Ethernet (PoE), Stroom

Nog 16 beschikbaar

Fabrikant Digitus
MPN DN-95108
EAN 4016032464501
€ 42,00 excl. BTW

Digitus DN-95108 PoE adapter & injector 10 Gigabit Ethernet 52 V

Power supply and data transfer with up to 10G bandwidth and 30 watt output with just one network cable, for PoE-enabled devices such as access points, IP phones or IP cameras

- PoE power supply with up to 30 W and 10 Gbps
- Supports the IEEE 802.3af/at PoE standard
- Supports 10G, 5G, 2.5G, 10/100/1000 Base-T
- PoE output: 30 W
- For distances of up to 100 m
- LED operating display
- Integrated power connection for non-heating appliances (C14)
- Excess voltage and short circuit protection
- Automatic detection of PoE devices
- Suitable for wall installation

The PoE+ injector from DIGITUS® offers a 30 watt PoE port as a midspan solution. Compact, cost-effective and fully IEEE802.3at-compliant. With support for 10 Gbps network connections, the PoE injector can also be used in environments where the highest possible data transfer speed is essential. The simple solution for remote power supply of wireless access points, IP security camera, VoIP phones and other installations with PoE functionality. The injector makes an external power supply for your devices unnecessary, eliminating the connected power cables / plugs. PoE & PoE+ compatible devices can be supplied with power and data using the network cable, a secure and reliable solution for expanding the existing network infrastructure.
  • Supports 10G, 5G, 2.5G and 10/100/1000 Base-T applications
  • Supports standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
  • LED display: Power input / PoE output
  • PoE output: 30 W
  • For distances of up to 100 m
  • LED operating display
  • Integrated power connection for non-heating appliances (C14)
  • Excess voltage and short circuit protection
  • Automatic detection of PoE devices
  • Suitable for wall installation
  • Power supply: 100 - 240 VAC / 50/60 Hz
  • Total power consumption: 32 W max.
  • PoE voltage: 52 VDC / 0.58 A
  • PoE budget: 30 W
  • PIN assignment: V+ (RJ45 Pin 3, 6), V- (RJ45 Pin 1, 2)
  • Operating temperature: 0 to 40°C
  • Storage temperature: -10 °C to 70 °C
  • Operating humidity: 5 - 95% (non condensing)
  • Dimensions: 145.5 x 61.5 x 40 mm (L x W x H)
  • Weight: 0.45 kg

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Netwerk

Ethernet interface type
10 Gigabit Ethernet
Ethernet LAN, data-overdrachtsnelheden
10,100,1000,2500,5000,10000 Mbit/s
Power over Ethernet (PoE)
Ja
Netwerkstandaard
IEEE 802.3at

Kenmerken

Kleur van het product
Zwart
Ophangsysteem voor aan de muur
Ja
Maximale afstand
100 m
LED-indicatoren
Power over Ethernet (PoE), Stroom
Stroomspanning bescherming
Kortsluiting
Land van herkomst
China

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten
2

Energie

Stroom via Ethernet (PoE)*
52 V
AC-adapter ingangsspanning
100-240 V
AC-adapterfrequentie
50/60 Hz
Stroom
0.58 A
Totaal Power over Ethernet (PoE)-budget
30 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Temperatuur bij opslag
-10 - 70 °C

Gewicht en omvang

Breedte
61,5 mm
Diepte
145,5 mm
Hoogte
40 mm
Gewicht
450 g

Verpakking

Breedte verpakking
120 mm
Diepte verpakking
60 mm
Gewicht verpakking
520 g
Verpakkingsvolume
1260 cm³

Inhoud van de verpakking

Aantal producten inbegrepen
1 stuk(s)

Logistieke gegevens

Code UK-handelstarief
85176200
Code geharmoniseerd systeem (HS)
85044095
