Digitus DN-95402-1-FR energiedistributie 8 AC-uitgang(en) 1U
Digitus DN-95402-1-FR, 1U, Horizontaal/Verticaal, Aluminium, Kunststof, 8 AC-uitgang(en), Type E, Type E
Ruim op voorraad
Fabrikant
Digitus
MPN
DN-95402-1-FR
EAN
4016032481959
€ 29,00
excl. BTW
€ 29,00
excl. BTW
excl. BTW
Digitus DN-95402-1-FR energiedistributie 8 AC-uitgang(en) 1U
Safe and professional current supply in the 19" range
- Perfect power source for your 482.6 mm (19”) housing
- Safety thanks to doubly grounded safety plug
- Jacks are rotated by up to 35°, which offers optimal space management and easy access
- The illuminated switch is protected against accidentally being switched off
The DIGITUS® socket strips are the perfect solution for your network or server cabinet. With regard to current distribution, the PDU fulfills the requirements of many applications in IT, network technology, laboratories and also home use. It can be attached horizontally or vertically and it is possible, depending on the type of cabinet, to mount the power strip with the taps facing upwards or downwards.
- Perfect power source for your 482.6 mm (19”) housing
- Safety thanks to doubly grounded safety plug
- Jacks are rotated by up to 35°, which offers optimal space management and easy access
- The illuminated switch is protected against accidentally being switched off
The DIGITUS® socket strips are the perfect solution for your network or server cabinet. With regard to current distribution, the PDU fulfills the requirements of many applications in IT, network technology, laboratories and also home use. It can be attached horizontally or vertically and it is possible, depending on the type of cabinet, to mount the power strip with the taps facing upwards or downwards.
- Horizontal 19" installation in the rack
- Switch - protected against accidentally being switched off
- Socket rotation: 35°
- Housing: Aluminum profile
- Plastic components made of ABS UL-94V-0
- Input: Safety plug with grounding contact, 230 Vac / 16 A
- Output: 8 x CEE 7/5, max. 16 A per output
- Cable: Cable cross section: 1.5 mm², length: 2 m
- Dimensions: 482.6 mm (19") x 45 (1U) x 45 mm (HxWxD)
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Design
Rackcapaciteit*
1U
Montage
Horizontaal/Verticaal
Materiaal behuizing
Aluminium, Kunststof
Aan/uitschakelaar
Ja
Poorten & interfaces
Aantal AC uitgangen*
8 AC-uitgang(en)
Stekker
Type E
Stopcontacttypes*
Type E
Aantal masterstopcontacten
8
Kenmerken
Snoerlengte
2 m
Energie
Nominale input voltage*
230 V
AC-ingangsfrequentie
50 - 60 Hz
Stroom (max.)*
16 A
Spanning
250 V
Maximaal vermogen
4000 W
Gewicht en omvang
Breedte
45 mm
Diepte
45 mm
Hoogte
482,6 mm
Gewicht
860 g
Maat
48,3 cm (19")
Verpakking
Gewicht verpakking
980 g
Breedte verpakking
510 mm
Diepte verpakking
97 mm
Hoogte verpakking
91 mm
Verpakkingsvolume
2869,26 cm³
Inhoud van de verpakking
Gebruikershandleiding
Ja
Rekbevestigingspakket
Ja
Logistieke gegevens
Land van herkomst
China
