Digitus DN-95407-FR energiedistributie 7 AC-uitgang(en) 1U

Digitus DN-95407-FR, Geschakeld, 1U, Rackmontage, Horizontaal, Aluminium, Kunststof, 7 AC-uitgang(en)

Niet op voorraad

Fabrikant Digitus
MPN DN-95407-FR
EAN 4016032481966
€ 29,00 excl. BTW

Digitus DN-95407-FR energiedistributie 7 AC-uitgang(en) 1U

Safe and professional current supply in the 19" range

- Perfect current distribution for your network and IT rack
- Integrated surge protection protects connected users from overvoltage.
- Jacks are rotated by up to 35°, which offers optimal space management and easy access
- Compact construction, 19" 1U housing

The DIGITUS® socket strips are the perfect solution for your network or server cabinet. With regard to current distribution, the PDU fulfills the requirements of many applications in IT, network technology, laboratories and also home use. The socket strip can be compactly mounted in the cabinet in the 19" area of 1U. Surge protection protects the user from overvoltage. The integrated switch is equipped with a cover, this protects the power strip from being accidentally switched off.
  • Surge protection module against overvoltage
  • Surge protection: Nominal discharge current (In) – 5 kA
  • Switch - protected against accidentally being switched off
  • Horizontal 19" installation in the rack
  • Socket rotation: 35°
  • Housing: Aluminum profile
  • Plastic components made of ABS UL-94V-0
  • Input: Plug grounding contact CEE 7/7, 230 Vac / 16 A
  • Output: 7 x CEE 7/5, max. 16 A per output
  • Cable: Cable cross section: 1.5 mm², length: 2 m
  • Dimensions: 482.6 mm (19") x 45 (1U) x 45 mm (HxWxD)

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Design

PDU types*
Geschakeld
Vormfactor
Rackmontage
Rack-montage
Ja
Rackcapaciteit*
1U
Montage
Horizontaal
Materiaal behuizing
Aluminium, Kunststof
Aan/uitschakelaar
Ja

Poorten & interfaces

Aantal AC uitgangen*
7 AC-uitgang(en)
Stekker
Type F
Stopcontacttypes*
Type E

Kenmerken

Spanningsbeveiliging
Ja
Snoerlengte
2 m

Energie

Nominale input voltage*
230 V
AC-ingangsfrequentie
50 - 60 Hz
Stroom (max.)*
16 A

Energie

Spanning
250 V
Stroomspanning bescherming
Overspanning

Gewicht en omvang

Breedte
45 mm
Diepte
45 mm
Hoogte
482,6 mm
Maat
48,3 cm (19")

Verpakking

Breedte verpakking
510 mm
Diepte verpakking
97 mm
Verpakkingsvolume
2869,26 cm³

Inhoud van de verpakking

Gebruikershandleiding
Ja
Rekbevestigingspakket
Ja

Logistieke gegevens

Land van herkomst
China
