Digitus DN-95435 energiedistributie 12 AC-uitgang(en) 1U
Digitus DN-95435, 1U, Eenfasig, Verticaal, Aluminium, Kunststof, 12 AC-uitgang(en), Type F
Nog 2 beschikbaar (bel voor reservering)
Fabrikant
Digitus
MPN
DN-95435
EAN
4016032483618
€ 36,00
excl. BTW
€ 36,00
excl. BTW
excl. BTW
Digitus DN-95435 energiedistributie 12 AC-uitgang(en) 1U
Safe and professional current supply in the network / server cabinet range
- Perfect current distribution for your network and IT rack
- The illuminated switch is protected against accidentally being switched off
- Integrated surge protection protects connected users from overvoltage.
- Jacks are rotated by up to 35°, which offers optimal space management and easy access
The DIGITUS® socket strips are the perfect solution for your network or server cabinet. With regard to current distribution, the PDU fulfills the requirements of many applications in IT, network technology, laboratories and also home use. The socket strip can be mounted vertically in the cabinet. Surge protection protects the user from overvoltage. It is possible, depending on the type of cabinet, to mount the power strip with the taps facing right or left.
- Perfect current distribution for your network and IT rack
- The illuminated switch is protected against accidentally being switched off
- Integrated surge protection protects connected users from overvoltage.
- Jacks are rotated by up to 35°, which offers optimal space management and easy access
The DIGITUS® socket strips are the perfect solution for your network or server cabinet. With regard to current distribution, the PDU fulfills the requirements of many applications in IT, network technology, laboratories and also home use. The socket strip can be mounted vertically in the cabinet. Surge protection protects the user from overvoltage. It is possible, depending on the type of cabinet, to mount the power strip with the taps facing right or left.
- Vertical installation
- Illuminated switch - protected against accidental
- Surge protection module against overvoltage
- Surge protection: Nominal discharge current (In) – 5 kA
- Socket rotation: 35°
- Housing: Aluminum
- Plastic components made of ABS UL-94V-0
- Input: Plug grounding contact CEE 7/7, 230 Vac / 16 A
- Output: Device socket 12 x grounding contact DIN 49440, max. 16 A per output
- Cable: H05VV-F 3G 1.5 mm², length: 2 m
- Dimensions: 643.9 x 45 x 45 mm (HxWxD)
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Design
Soort
Eenfasig
Rackcapaciteit*
1U
Montage
Verticaal
Materiaal behuizing
Aluminium, Kunststof
Aan/uitschakelaar
Ja
Poorten & interfaces
Aantal AC uitgangen*
12 AC-uitgang(en)
Stekker
Type F
Stopcontacttypes*
Type F
Aantal masterstopcontacten
12
Kenmerken
Spanningsbeveiliging
Ja
Energie
Nominale input voltage*
230 V
AC-ingangsfrequentie
50 - 60 Hz
Stroom (max.)*
16 A
Spanning
230 V
Laad-capaciteit
3600 VA
Aantal fases
1
Energie
Stroomspanning bescherming
Overspanning
Gewicht en omvang
Breedte
45 mm
Diepte
45 mm
Hoogte
643,9 mm
Maat
48,3 cm (19")
Verpakking
Gewicht verpakking
486,349 g
Breedte verpakking
900 mm
Diepte verpakking
120 mm
Hoogte verpakking
58 mm
Verpakkingsvolume
6264 cm³
Inhoud van de verpakking
Gebruikershandleiding
Ja
Rekbevestigingspakket
Ja
Logistieke gegevens
Land van herkomst
China
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
