Digitus DS-30222 interfacekaart/-adapter Intern USB 3.2 Gen 2 (3.1 Gen 2), USB Type-C

Digitus DS-30222, PCIe, USB 3.2 Gen 2 (3.1 Gen 2), USB Type-C, PCI 2.0, Zwart, Nikkel, PC, China

Ruim op voorraad

Fabrikant Digitus
MPN DS-30222
EAN 4016032485810
€ 55,00 excl. BTW

Digitus DS-30222 interfacekaart/-adapter Intern USB 3.2 Gen 2 (3.1 Gen 2), USB Type-C

USB 3.1 Gen2 Super Speed up to 10 Gbps

- USB 3.1 PCI Express Interface Card with 5 external USB 3.1 ports: 3x USB A jack, 2x USB-C jack for devices of the latest generation
- 2x USB-C (USB 3.1 Gen2) up to 10 Gbps
- 3x USB-A (USB 3.1 Gen2) up to 10 Gbps
- Supports data transfer rates of 10G / 5G / 480M / 12M / 1.5Mbps
- Power supply: USB-C 5V/3A per port max.
- Power supply: USB A 5V/1A per port max.
- Plug and Play - no driver installation required

The Digitus PCI Express Card extends the PC by 2x USB-C and 3x USB A ports. Various devices can be connected to this card, such as hard disks, DVD drives, mouse, keyboard, card reader and more.
  • USB 3.1 Super Speed up to 10 Gbits
  • 2 x SuperSpeed USB 10 Gbps (USB 3.1 Gen 2) USB Type-C™ jack
  • 3 x SuperSpeed USB 10 Gbps (USB 3.1 Gen2) A jack
  • Each port supports a transfer rate of up to 10 Gbps (USB3.1 Gen.2)
  • Supports data transfer rates of 10G / 5G / 480 / 12 / 1.5 Mbps
  • Output USB Type-C™ Port 5 V / 3 A
  • Output USB Type A Port 5 V / 1 A
  • Support of 4-way PCI Express v2.0
  • Supports eXtensible Host Controller Interface (xHCI) Specification 1.1
  • Supports Multiple INs
  • Surge protection
  • Supported operating systems: Windows 7/8/8.1/10/11, Linux
  • Number of USB A ports: 3
  • Number of USB C ports: 2

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Hostinterface*
PCIe
Output interface*
USB 3.2 Gen 2 (3.1 Gen 2), USB Type-C
Uitbreidingskaartstandaard
PCI 2.0
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A
3
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C
2

Design

Intern*
Ja
Kleur van het product
Zwart, Nikkel
Bedoeld voor
PC
Land van herkomst
China

Kenmerken

Data transfer snelheid (max)
10 Gbit/s

Energie

Spanning
5 V
Output current
3 A

Minimale systeemeisen

Ondersteunt Windows
Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1

Minimale systeemeisen

Ondersteunt Linux
Ja

Gewicht en omvang

Breedte
94 mm
Diepte
120 mm
Hoogte
22 mm

Verpakking

Aantal per verpakking
1 stuk(s)
Meegeleverde drivers
Ja
Breedte verpakking
175 mm
Diepte verpakking
30 mm
Hoogte verpakking
130 mm
Gewicht verpakking
160,25 g
Verpakkingsvolume
682,5 cm³

Logistieke gegevens

Code UK-handelstarief
84718000
