Digitus DS-33170 interfacekaart/-adapter Intern M.2

Digitus DS-33170, PCIe, M.2, PCI 3.0, Zwart, China, 6 Gbit/s

Ruim op voorraad

Fabrikant Digitus
MPN DS-33170
EAN 4016032464419
€ 12,00 excl. BTW

Digitus DS-33170 interfacekaart/-adapter Intern M.2

Use M.2 NGFF/NVMe SSDs at PCIe x4 slots on the mainboard – B & M key

- NGFF/NVMe SSD M.2 adapter card for PCIe slots: x4/x8/x16
- Supports NVMe Key B/M M.2 SSD including 2230, 2242, 2260 & 2280
- Supports M-Key M.2 SSD, B-Key and B+M Key M.2 SSD
- Ultra-fast PCI express V3.0 data transfer at up to 6 Gbps / 32 GT/s
- Supports PCIe 3.0 / SATA 3.0
- Low-profile slot bracket included

This PCIe x4 adapter card is suitable for M.2 / NGFF storage media (NVMe) with B, M, B+M key and the dimensions 2230, 2242, 2260 & 2280. Together with the x4 interface and PCIe 3.0 standard, data transfers of up to 6 Gbps (32 GT/s) are possible. Storage media can either be connected via the integrated SATA interface for M.2 SATA SSDs, or via the PCI interface for NVMe PCIe SSDs. Go into turbo mode with the multi-functional M.2 PCIe 3.0 add-on card from DIGITUS®.
  • Adapter Card for PCIe Slots x4/ x8/ x16
  • Supports PCIe 3.0 (x4)
  • Data transfer rate: up to 6Gbps (32GT/S)
  • Supports NVMe Key B/M M.2 SSD including 2230, 2242, 2260 & 2280
  • Hard disk sizes: 80, 60, 42 & 30 mm
  • Supports M-Key M.2 SSD, B-Key and B+M Key M.2 SSD
  • Bus type: PCIe 3.0 (complies with PCI express specification Rev. 3)
  • SATA: 3.0 (complies with SATA specification Rev. 3)
  • Backwards compatible with PCIe 2.0 and 1.0 mainboards
  • Power supply via PCIe interface (3.3 V)
  • Supported operating systems: Windows10/8/8.1/Server 2012 R2/Linux/Ubuntu
  • Dimensions: 11.4 x 7 x 2 cm (W x D x H)
  • Weight: 41.2 g

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Hostinterface*
PCIe
Output interface*
M.2
Uitbreidingskaartstandaard
PCI 3.0
NVMe
Ja
SATA herziening
3.0
Aantal M.2 (M) slots
2

Design

Intern*
Ja
Kleur van het product
Zwart
Land van herkomst
China

Kenmerken

Data transfer snelheid (max)
6 Gbit/s

Gewicht en omvang

Breedte
114 mm
Diepte
70 mm
Hoogte
20 mm
Gewicht
41,2 g

Verpakking

Aantal
1
Meegeleverde kabels
SATA
Montagebeugels meegeleverd
Ja
Snelle installatiehandleiding
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84733020
