Eaton 9PX Dubbele conversie (online) 1,5 kVA 1500 W 8 AC-uitgang(en)

Eaton 9PX, Dubbele conversie (online), 1,5 kVA, 1500 W, Sinus, 176 V, 276 V

Niet op voorraad

Fabrikant Eaton
MPN 9PX1500IRT2U-L
EAN 0743172105479
€ 2.746,00 excl. BTW

Eaton 9PX Dubbele conversie (online) 1,5 kVA 1500 W 8 AC-uitgang(en)

Eaton 9PX 1500i RT2U Li-Ion
  • 9PX is the first UPS in its class to provide Unity power factor (VA=W). It delivers 11% more power than any other UPS as well as powering more servers with equivalent VA ratings and lower power factors
  • Energy Star qualified, the 9PX provides the highest efficiency level to reduce energy and cooling costs
  • Double conversion topology. The Eaton 9PX constantly monitors power conditions and regulates voltage and frequency
  • The graphical LCD display provides clear information on the UPS’s status and measurements on a single screen. Enhanced configuration capabilities are also available
  • 9PX can meter energy consumption right down to the managed outlet groups. kWh values can be monitored using the LCD or Eaton’s Intelligent PowerTM Software
  • Load segment control enables prioritised shutdowns of non-essential equipment to maximize battery runtime for critical devices
  • 9PX offers Serial and USB connectivity, plus an extra slot for an optional communication card. Eaton’s Intelligent Power Software seamlessly integrates with leading virtualisation environments and cloud orchestrations tools
  • The internal bypass allows service continuity in case of internal fault, a maintenance bypass is also available (as standard on HotSwap version) for easy replacement of the UPS
  • Stronger, longer battery life: Eaton ABM® battery management technology uses an innovative three-stage charging technique that extends battery life by up to 50%
  • More runtime can be added with up to 4 external hot-swappable battery modules, able to run systems for hours if necessary

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

UPS-topologie*
Dubbele conversie (online)
Output power capacity*
1,5 kVA
Uitgangsvermogen*
1500 W
Golfvorm*
Sinus
Ingang operation voltage (min)*
176 V
Ingang operation voltage (max)*
276 V
Frequentie*
40/70 Hz
Uitgang operation voltage (min)
200 V
Uitgang operation voltage (max)
240 V
Output frequentie
50/60 Hz
Aantal input fases
1
Aantal output fases
1
Efficientie
92,5 procent
Input vermogensfactor
0,99
Output vermogensfactor
1
Output voltage THD
3 procent
Geluidsniveau
35 dB
Automatisch uitschakelen
Ja

Poorten & interfaces

Stopcontacttypes
C13 stekker
Stekker
C14 stekker
Aantal AC uitgangen
8 AC-uitgang(en)
USB-poort
Ja
Aantal USB 2.0-poorten
1
Seriële interface
Ja
Soort serieële aansluiting
RS-232
Seriële poort(en)
1

Accu/Batterij

Batterijtechnologie
Lithium-Ion (Li-Ion)

Accu/Batterij

Hot-swap batterij
Ja

Design

Vormfactor*
Rackmontage/toren
Rackcapaciteit
2U
Kleur van het product*
Zwart, Zilver
Type beeldscherm
LCD
Veiligheid
IEC/EN 62040-1, UL 1778, CSA 22.2
Certificering
IEC/EN 62040-2, FCC, CISPR22, CE, CB, TUV, cULus, EAC, RCM, KC

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 96 procent
Hoogte, in bedrijf
0 - 3000 m

Technische details

Duurzaamheidscertificaten
ENERGY STAR

Gewicht en omvang

Breedte
440 mm
Diepte
450 mm
Hoogte
86,5 mm
Gewicht
18,9 kg

Verpakking

Rekbevestigingspakket
Ja
Meegeleverde kabels
Uitgangsstroomkabel, Serie
Snelle installatiehandleiding
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85078000

Overige specificaties

Bypass
Internal
