Intel Core i3-8100T processor 3,1 GHz 6 MB Smart Cache

Intel Core i3-8100T, Intel® Core™ i3, LGA 1151 (Socket H4), 14 nm, Intel, i3-8100T, 3,1 GHz

Ruim op voorraad

Fabrikant Intel
MPN CM8068403377415
EAN 8592978095505
€ 220,00 excl. BTW

Intel Core i3-8100T processor 3,1 GHz 6 MB Smart Cache

Get Unprecedented Power and Responsiveness
Now everyday computer tasks can happen faster. Edit photos and videos seamlessly. Move between programs and windows quickly. Multitask easily. Better still, all that performance comes with up to 10 hours of battery life1 2, so you can take your computer wherever you go without worrying about cords and plug points.

Make Your Computer an Entertainment Center
Get an amazing entertainment hub—stream 4K UHD videos, power virtual reality, and play the most demanding games. With 4x more pixels on screen than traditional HD, you can enjoy sharp, lifelike visuals, complex shading, and fast frame rates—all with virtually no stuttering, buffering, or lags. And be ready for revolutionary immersive experiences yet to come.

Easy to Use, Hard to Break Into
Built-in security3 adds a critical layer of protection to make password logons, browsing, and online payments safe3 and simple. You can log on with a look, your voice, or your fingerprint for rock-solid security3 that’s fast and hassle free. Store passwords, personal information, and auto-fill information with one master password. Plus touch screen, voice commands, and stylus options offer natural and intuitive interactions.

Thunderbolt™ 3 Technology
Remove the burden of multiple cables and get one compact port that does it all - power your PC, transfer data, and connect with dual 4K UHD displays.

Intel® Graphics Technology
Immerse yourself in vivid entertainment with the brilliance of Intel® Graphics Technology.

Intel® Online Connect
With Intel® Online Connect, security is built-in 7th Generation Intel® Core™ processors and above, which adds a layer of protection to make browsing and online payments safe4 and simple.

Intel® Optane™ Technology
Eliminating bottlenecks requires better storage memory that is fast, inexpensive, and non-volatile. With Intel® Optane™ technology, you can unleash the power of your processor instead of it working at a fraction of it.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
Intel® 8de generatie Core™ i3
Processormodel*
i3-8100T
Basisfrequentie processor*
3,1 GHz
Processorfamilie*
Intel® Core™ i3
Aantal processorkernen*
4
Processor socket*
LGA 1151 (Socket H4)
Component voor
PC
Processor lithografie*
14 nm
Processorserie
Intel Core i3-8100 Desktop series
Processor aantal threads
4
Systeembus
8 GT/s
Processor operating modes*
64-bit
Processor cache
6 MB
Processor cache type
Smart Cache
Thermal Design Power (TDP)
35 W
Box*
Nee
Configureerbare TDP-downfrequentie
2,4 GHz
Inclusief koeler*
Nee
Configureerbare TDP-down
25 W
Generatie
8th Generation
Stepping
B0
Bus type
DMI3
Geheugenbandbreedte ondersteund door de processor ( max)
37,5 GB/s
Codenaam processor
Coffee Lake
Processorcode
SR3Y8
ARK ID processor
129944

Geheugen

Maximaal intern geheugen ondersteund door processor
64 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor
2400 MHz
Geheugen kanaal*
Dubbelkanaals
ECC
Ja

Grafisch

Ingebouwde grafische adapter*
Ja
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Intel® UHD Graphics 630
Maximaal geheugen ingebouwde grafische adapter
64 GB
On-board ondersteunde grafische adapter uitgangen
Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI
Basisfrequentie ingebouwde grafische adapter
350 MHz
Graphics on-board -adapter dynamische frequentie (max)
1100 MHz
Aantal displays ondersteund (door on-board grafische adapter)
3
4K-ondersteuning
Ja
On-board grafische adapter DirectX-versie
12.0
On-board grafische adapter OpenGL versie
4.5
Graphics aan boord maximale resolutie adapter (DisplayPort )
4096 x 2304 Pixels
Maximale resolutie (eDP - Integrated Flat Panel)
4096 x 2304 Pixels
Maximale resolutie ingebouwde grafische adapter (HDMI)
4096 x 2304 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP - Integrated Flat Panel)
60 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
24 Hz
On-board grafische adapter ID
0x3E91
Discreet grafische adapter model*
Niet beschikbaar

Kenmerken

Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Marktsegment
Desktop
Maximaal aantal PCI Express-lijnen
16
PCI Express slots versie
3.0
PCI Express configuraties
1x16, 2x8, 1x8+2x4
Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0
Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Ja

Kenmerken

Thermal solution specificatie
PCG 2015A
PCI Express CEM revisie
3.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Nee
Intel® Identity Protection Technology (Intel® IPT)
Ja
Intel® Turbo Boost Technology
Nee
Intel® Quick Sync Video Technology
Ja
Intel® InTru™ 3D Technology
Ja
Intel® Clear Video HD Technology (Intel® CVT HD)
Ja
Intel® Smart Cache
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Trusted Execution Technology
Nee
Intel® Memory Protection Extensions (Intel® MPX)
Ja
Intel® Transactional Synchronization Extensions
Nee
Intel® Enhanced Halt State
Ja
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID)
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® TSX-NI
Nee
Intel® Stable Image Platform Program (SIPP)
Nee
Intel® OS Guard
Ja
Intel® Clear Video-technologie
Ja
Intel® Software Guard Extensions (Intel® SGX)
Ja
Intel® 64
Ja
Versie Intel® Identity Protection Technology
1,00
Versie Intel® Secure Key Technology
1,00
Versie Intel® Stable Image Platform Program (SIPP)
0,00
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Versie Intel® TSX-NI
0,00
Intel® Optane™ Memory Ready
Ja
Intel® Boot Guard
Ja
Intel® vPro™ Platform Eligibility
Nee

Eisen aan de omgeving

Tjunction
82 °C

Technische details

Bandbreedte bus
8
Type buseenheden
GT/s
Lanceringsdatum
Q2'18
Maximale resolutie & verversingsfrequentie (DisplayPort)
4096x2304@60Hz
Maximale resolutie & verversingsfrequentie (HDMI)
4096x2304@24Hz
Maximale resolutie & verversingsfrequentie (Integrated Flat Panel)
4096x2304@60Hz
Processorcache
6144 KB
Type product
Processor
Status
Launched
Maximaal geheugen
64 GB
Merknaam processor
8th Gen Intel Core i3 8th Gen Intel Core i3 Processor
Ondersteunde geheugen types
DDR4-SDRAM
Laatste wijziging
63903513
Productfamilie
Intel Core Processors
Bussnelheid
8 GT/s
Maximaal geheugen grafische adapter
64 GB
Processor-id
0x3E91

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85423119

Gewicht en omvang

Verpakkingsgrootte processor
37.5 x 37.5 mm

Overige specificaties

Maximum intern geheugen
64 GB
Maximaal intern geheugen
65536 MB
Grafische uitvoer
eDP/DP/HDMI/DVI
