Intel E810CQDA2OCPV3 netwerkkaart Intern

Intel E810CQDA2OCPV3, Intern, PCI Express

Nog 12 beschikbaar

Fabrikant Intel
MPN E810CQDA2OCPV3
EAN 0735858456883
€ 898,00 excl. BTW

Intel E810CQDA2OCPV3 netwerkkaart Intern

iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.

Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.

PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.

Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.

Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Hostinterface*
PCI Express
Aantal Ethernet LAN (RJ-45)-poorten
2
Vezel-optische connector
QSFP28
PCI versie
4.0

Netwerk

Ethernet LAN, data-overdrachtsnelheden
1000,10000,25000,50000,100000 Mbit/s
LAN controller
Intel E810

Design

Intern*
Ja

Minimale systeemeisen

Compatibele besturingssystemen
https://www.intel.com/content/www/us/en/support/articles/000025890/ethernet-products.html

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990

Overige specificaties

Soort kabel
QSFP28 ports - DAC, Optics, AOC's
Intel® Virtual Machine Device Queues (VMDq)
Ja
PCI-SIG* SR-IOV Capable
Ja
On-chip QoS and Traffic Management
Ja

Overige specificaties

Intel® Flexible Port Partitioning
Ja
Snelheid en sleuf breedte
16.0 GT/s, x16 Lane
Intelligent Offloads
Ja
iWARP/RDMA
Ja
Intel® Data Direct I/O Technology
Ja
Intel® Virtualization Technology for Connectivity (VT-c)
Ja
Opslag via ethernet
iSCSI, NFS
Lanceringsdatum
Q3'20
Kaartkabeldrager netwerkinterface
Copper
Kaarttype netwerkinterface
Server
Status
Launched
Processorfamilie
800 Network Adapters (up to 100GbE)-800 Network Adapters (up to 100GbE)
Export Control Classification Number (ECCN)
5A991
Commodity Classification Automated Tracking System (CCATS)
NA
Brackethoogte
OCP 3.0
Productserie
800 Series Network Adapters (up to 100GbE)
