Intel Xeon Silver 4410Y processor 2 GHz 30 MB

Intel Xeon Silver 4410Y, Intel® Xeon® Silver, FCLGA4677, Intel, 4410Y, 2 GHz, Intel Xeon Scalable 4th Gen

Ruim op voorraad

Fabrikant Intel
MPN PK8071305120002
EAN 8592978435424
€ 602,00 excl. BTW

Intel Xeon Silver 4410Y processor 2 GHz 30 MB

Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Crypto Acceleration
Intel® Crypto Acceleration reduces the performance impact of pervasive encryption and increases the performance of encryption-intensive workloads including SSL web serving, 5G infrastructure, and VPN/firewalls.

Intel® Software Guard Extensions (Intel® SGX)
Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Intel® SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE’s).

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

Intel® Total Memory Encryption
TME – Total Memory Encryption (TME) helps protect data against exposure via physical attack on memory, such as cold-boot attacks.

Max # of UPI Links
Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI.

# of AVX-512 FMA Units
Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.

Intel® Resource Director Technology (Intel® RDT)
Intel® RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.

Intel® Speed Select Technology - Performance Profile
A capability to configure the processor to run at three distinct operating points.

Mode-based Execute Control (MBEC)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.

Intel® Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.

Intel® Transactional Synchronization Extensions
Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
Intel Xeon Scalable 4th Gen
Processormodel*
4410Y
Basisfrequentie processor*
2 GHz
Processorfamilie*
Intel® Xeon® Silver
Aantal processorkernen*
12
Processor socket*
FCLGA4677
Processor aantal threads
24
Systeembus
16 GT/s
Maximale turbofrequentie van processor
3,9 GHz
Processor cache
30 MB
Thermal Design Power (TDP)
150 W
Box*
Nee
Stepping
S3
Codenaam processor
Sapphire Rapids
ARK ID processor
232376

Geheugen

Maximaal intern geheugen ondersteund door processor
6000 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM
Geheugen kanaal*
Achtkanaals
ECC
Ja

Grafisch

Ingebouwde grafische adapter*
Nee
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Niet beschikbaar
Discreet grafische adapter model*
Niet beschikbaar

Kenmerken

Execute Disable Bit
Ja
Marktsegment
Server
Gebruiksvoorwaarden
Server/Enterprise
Maximaal aantal PCI Express-lijnen
80
PCI Express slots versie
5.0
Ondersteunde instructie sets
AMX, SSE4.2, AVX, AVX 2.0, AVX-512
Schaalbaarheid
2S
Ingebouwde opties beschikbaar
Ja
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G180729

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Trusted Execution Technology
Ja

Processor speciale functies

Intel® Speed Shift-technologie
Ja
Intel® Transactional Synchronization Extensions
Ja
Intel® Total Memory Encryption
Ja
Intel® Control-flow Enforcement Technology (CET)
Ja
Intel® Crypto Acceleration
Ja
Ondersteuning voor Intel® Platform Firmware Resilience
Ja
Ondersteuning voor maximale enclavegrootte voor Intel® SGX
64 GB
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® OS Guard
Ja
Intel® Software Guard Extensions (Intel® SGX)
Ja
Intel® 64
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
AVX-512 Fused Multiply-Add (FMA) eenheden
2
Intel® Boot Guard
Ja
Intel® Deep Learning Boost (Intel® DL Boost)
Ja
Intel® Speed Select-technologie - Prestatieprofiel (Intel® SST-PP)
Ja
Intel® Resource Director-technologie (Intel® RDT)
Ja
Mode-based Execute Control (MBE)
Ja
Intel® QuickAssist-softwareversnelling
Ja
Intel® On Demand Feature Activation
Ja
Intel® Data Streaming Accelerator (DSA)
1 default devices
Intel® Advanced Matrix Extensions (AMX)
Ja

Eisen aan de omgeving

Tcase
78 °C
DTS Max
93 °C

Technische details

Lanceringsdatum
Q1'23
Status
Launched
Ondersteunde geheugen types
DDR4-SDRAM
Geheugensnelheid (max)
4000 MHz
Aantal UPI-koppelingen
2
Pakketvervoerder (package carrier)
E1B

Logistieke gegevens

Code geharmoniseerd systeem (HS)
8542310001

Verpakking

Type verpakking
Retaildoos

Gewicht en omvang

Verpakkingsgrootte processor
77.5 x 56.5 mm

Overige specificaties

Maximum intern geheugen
4000 GB
