Lenovo 4XB7A17081 internal solid state drive 3.5" 240 GB SATA III 3D TLC NAND
Lenovo 4XB7A17081, 240 GB, 3.5", 540 MB/s, 6 Gbit/s
Niet op voorraad
Fabrikant
Lenovo
MPN
4XB7A17081
EAN
0889488511068
€ 523,00
excl. BTW
€ 523,00
excl. BTW
excl. BTW
Lenovo 4XB7A17081 internal solid state drive 3.5" 240 GB SATA III 3D TLC NAND
The 5300 Entry SATA solid-state drives (SSDs) are new SSDs for ThinkSystem servers. The drives use Micron 96-layer 3D NAND flash memory technology with a SATA 6Gbps interface and provide an affordable solution for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
This product guide provides essential presales information to understand the 5300 Entry SSD offerings, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SSDs and consider their use in IT solutions.
This product guide provides essential presales information to understand the 5300 Entry SSD offerings, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SSDs and consider their use in IT solutions.
- Industry standard 2.5-inch or 3.5-inch form factors
- New generation 96-layer 3D TLC NAND flash memory
- 6 Gbps SATA host interface
- High reliability and enhanced ruggedness
- MTTF of 3 million device hours - 50% more than most drives
- Absence of moving parts to reduce potential failure points in the server
- S.M.A.R.T. support
- Advanced Encrypting Standard (AES) 256-bit encryption
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Kenmerken
Ondersteunde beveiligingsalgoritmen
256-bit AES
SSD-vormfactor*
3.5"
SSD capaciteit*
240 GB
Interface*
SATA III
Type geheugen*
3D TLC NAND
NVMe*
Nee
Component voor*
Server/werkplaats
Hardware encryptie*
Ja
Overdrachtssnelheid
6 Gbit/s
Leessnelheid
540 MB/s
Schrijfsnelheid
310 MB/s
Random read (4KB)
67 IOPS
Random write (4KB)
40 IOPS
Leeslatentie
175 µs
Schrijflatentie
300 µs
Hot-swap
Ja
Kenmerken
Mean time between failures (MTBF)
3000000 uur
Energie
Stroomverbruik (lezen)
2,5 W
Stroomverbruik (schrijven)
3 W
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 70 °C
Temperatuur bij opslag
-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Trillingsbestendigheid
3,13 G
Technische details
Duurzaamheidscertificaten
RoHS
Gewicht en omvang
Gewicht
70 g
Logistieke gegevens
Code geharmoniseerd systeem (HS)
84717070
