Supermicro SuperServer E300-8D server Mini (1U) Intel® Xeon® D D-1518 2,2 GHz DDR4-SDRAM

Supermicro SuperServer E300-8D, 2,2 GHz, D-1518, DDR4-SDRAM, Mini (1U)

Niet op voorraad

Fabrikant Super Micro
MPN SYS-E300-8D
EAN 0672042242344
€ 759,00 excl. BTW

Supermicro SuperServer E300-8D server Mini (1U) Intel® Xeon® D D-1518 2,2 GHz DDR4-SDRAM

SuperServers are Your Best Choice!

SuperServer Benefits:

- Uncompromising Quality Control
- The most Comprehensive Line of Servers, Storage Systems, and Subsystems
- Widest Variety of Application Optimized Solutions, from High End Clusters to MicroServers
- Best Performance per-Watt, per-Square-Foot, and per-Dollar
- Superior Product Design Based in Silicon Valley
- Consistently First-to-Market
- Best Total Cost of Ownership (TCO)
- Highest Quality Components and Materials
- 3-Year Limited Warranty
- 24-Hour Support and Global Services
- Redfish API support

These benefits combined with an excellent track record have earned Supermicro a reputation as a true leader in the high-end server/storage industry. Supermicro provides the most outstanding product line in the industry, ranging from single Atom™ and dual Xeon® to quad Xeon® MP systems. Their proven high level of quality and performance has made SuperServers the platform of choice for HPC, enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorfamilie*
Intel® Xeon® D
Processormodel*
D-1518
Frequentie van processor*
2,2 GHz
Maximale turbofrequentie van processor
2,2 GHz
Aantal processorkernen
4
Processor cache
6 MB
Geheugenkanalen ondersteund door processor
Dual
Aantal geïnstalleerde processoren
1
Thermal Design Power (TDP)
35 W
Processor cache type
L3
Processor socket
BGA 1667
Processor lithografie
14 nm
Processor aantal threads
8
Processor operating modes
64-bit
Stepping
V2
Codenaam processor
Broadwell
Maximaal intern geheugen ondersteund door processor
128 GB
Geheugentypen ondersteund door processor
DDR3-SDRAM, DDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor
1600,1866,2133 MHz
ECC ondersteund door processor
Ja
Voltage geheugen ondersteund door processor
1,2 V
Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Maximaal aantal PCI Express-lijnen
32
PCI Express configuraties
1x16, 1x4, 1x8
Verpakkingsgrootte processor
37.5 x 37.5 mm
Ondersteunde instructie sets
AVX 2.0
Processorcode
SR2DN
Schaalbaarheid
1S
Ingebouwde opties beschikbaar
Ja
Processorserie
Intel Xeon D-1500
Conflictvrije processor
Ja
Intelligent Platform Management Interface (IPMI) support
Ja

Geheugen

Intern geheugentype*
DDR4-SDRAM
Geheugenslots
4
ECC
Ja
Maximum intern geheugen*
128 GB

Opslagmedia

Ondersteunde HDD-groottes
2.5"
RAID support*
Ja
Soorten RAID
0, 1, 5, 10
Soort optische drive*
Nee
Ondersteunde opslagstationinterfaces
M.2, SATA III

Netwerk

LAN controller
Intel® I350-AM4, Intel i210
Ethernet LAN
Ja
Ethernet interface type
Gigabit Ethernet

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten*
6
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A
2
VGA (D-Sub)poort(en)
1
Aantal SATA III connectors
4
Totaal aantal SATA-connectoren
6

Uitbreidingsmodules

PCI Express x8 (Gen 3.x) slots
1
PCI Express slots versie
2.0, 3.0

Design

Type behuizing*
Mini (1U)

Prestatie

BIOS type
AMI
Trusted Platform Module (TPM)
Ja
Trusted Platform Module (TPM) version
2.0

Software

Meegeleverde software
Intel Node Manager, IPMI 2.0, KVM LAN, NMI, SUM, SuperDoctor 5, Watch Dog

Processor speciale functies

CPU configuratie (max)
1
Enhanced Intel SpeedStep Technology
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
Nee
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Trusted Execution Technology
Ja
Intel® Enhanced Halt State
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® TSX-NI
Ja
Intel® OS Guard
Ja
Intel® 64
Ja
Versie Intel® Secure Key Technology
1,00
Intel® Virtualization Technology (VT-x)
Ja
Versie Intel® TSX-NI
1,00
UART
Ja
ARK ID processor
91201

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
8 - 90 procent
Luchtvochtigheid bij opslag
5 - 95 procent

Certificaten

Certificering
RoHS

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84714100

Gewicht en omvang

Breedte
254 mm
Diepte
226 mm
Hoogte
43 mm
Gewicht
1,56 kg
Breedte verpakking
381 mm
Diepte verpakking
142 mm
Hoogte verpakking
276 mm
Gewicht verpakking
3,4 kg

Technische details

Aantal 2.5" bays
1

Overige specificaties

Flash memory
128 MB
Energiebeheer
Ja
Grafische adapter
AST2400
