Synology SA3400D data-opslag-server NAS Rack (2U) Ethernet LAN D-1541

Synology SA3400D, NAS, Rack (2U), Intel® Xeon® D, D-1541

Nog 15 beschikbaar

Fabrikant Synology
MPN SA3400D
EAN 4711174725212
€ 11.955,00 excl. BTW

Synology SA3400D data-opslag-server NAS Rack (2U) Ethernet LAN D-1541

Built-in High Availability
Keep file sharing services, block storage, backups, and other office applications online with automatic minute-level failover. Defend against operational disruptions with two independent and hot-swappable controllers operating in an active-passive configuration.

Made for demanding environments
The SA3400D is engineered to provide outstanding performance in both NAS and SAN storage roles. Its throughput and random I/O performance support efficient SMB and NFS file serving as well as a range of iSCSI and Fibre Channel block storage applications.

Consolidate your data infrastructure
Manage, protect, and share data with versatile business solutions. Empower team collaboration, sandbox applications, and provide VM storage on a unified platform.

Flexible options to meet changing needs
Flexibly scale storage capacity, optimize I/O performance, and meet different network needs with a range of expansion options.

Add storage capacity on demand
Scale server capacity up to 576 TB7 when your data storage needs increase by adding two 12-bay RXD1219sas expansion units.

Boost network and I/O performance
Add 10/25GbE connectivity with optional add-in cards.8 Create all-flash storage volumes with SAS SSD for lightening-fast I/O, or boost IOPS and cut down latency on HDD volumes by creating SAS SSD read/write cache volumes.

Performance backed by Synology drives
Engineered to handle intensive workloads, Synology hard drives consistently deliver top-grade performance.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Opslagmedia

Opslag schijf-interface*
Serial Attached SCSI (SAS)
Opslagschijf afmetingen ondersteund
2.5,3.5"
RAID support*
Ja
Soorten RAID
0, 1, 5, 10, JBOD
Hot-swap drive bays
Ja
Ondersteunde bestandsystemen
BTRFS, ext4
Opslagdrives geïnstalleerd*
Nee
Aantal storage drives ondersteund*
12
Geïnstalleerde opslag-drive*
Nee
Ondersteunde types opslag-drives*
HDD & SSD

Processor

Processorfabrikant*
Intel
Processorfamilie*
Intel® Xeon® D
Processormodel*
D-1541
Frequentie van processor*
2,1 GHz
Maximale turbofrequentie van processor
2,7 GHz
Aantal processorkernen
8
Processor cache
12 MB
CPU configuratie (max)
1

Geheugen

Intern geheugentype
DDR4
Ondersteund maximum RAM
64 GB
Intern geheugen*
8 GB

Netwerk

Ethernet LAN*
Ja
Ondersteunde netwerkprotocollen
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Verbindingsaggregatie
Ja

Poorten & interfaces

USB-poort*
Nee
Aantal Ethernet LAN (RJ-45)-poorten*
3

Design

Type behuizing*
Rack (2U)
Type koeling*
Actief
Aantal ventilatoren
2 ventilator(en)
Ventilator diameter
6 cm

Prestatie

Soort*
NAS
Backup-functie*
Ja
Aantal gebruikers
16000 gebruiker(s)
Access Control List (ACL)
Ja
Reset button
Ja

Energie

Capaciteit voedingsunit (PSU)
500 W
Aantal voedingen
2
Redundante voeding
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50/60 Hz

Gewicht en omvang

Breedte*
482 mm
Diepte*
724 mm
Hoogte*
88 mm
Gewicht
19,7 kg

Processor speciale functies

Versie Intel® Secure Key Technology
1,00
Versie Intel® TSX-NI
1,00

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 35 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Temperatuur bij opslag
-20 - 60 °C
