TP-Link TL-SG2008P netwerk-switch Managed L2/L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

TP-Link TL-SG2008P, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack-montage

Ruim op voorraad

MPN TL-SG2008P
EAN 6935364072957
€ 157,00 excl. BTW

TP-Link TL-SG2008P netwerk-switch Managed L2/L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

Smarter Switching for Smarter Results
JetStream 8-Port Gigabit Smart Switch with 4-Port PoE+


Multiple Application Scenarios
The TL-SG2008P is fully compatible with PoE devices, such as IP cameras, access points, and IP phones. It also works with non-PoE wired devices to provide gigabit connections, such as PCs, printers, and IPTV.

Power over Ethernet for Simplified Network Deployment
Features four 802.3af/at compliant PoE+ ports, the switch supports up to 62 W total PoE power budget.* Designed to use a single Ethernet cable for both data and power transmission, it offers flexible deployment for PoE-supported devices such as wireless access points, IP cameras, and IP phones, lowering infrastructure costs for small businesses.

Omada SDN—Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.

Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
  • 62 W PoE Budget: 4× 802.3at/af-compliant PoE+ ports with a total power supply of 62 W*
  • Full Gigabit Ports: 4× gigabit PoE+ ports and 4× gigabit non-PoE ports provide high-speed connections
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management
  • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more
  • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2/L2+
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja
System event log
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Fast Ethernet (koperen) ports kwantiteit
8

Netwerk

Netwerkstandaard*
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Port mirroring
Ja
Datastroombeheer
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Auto MDI/MDI-X
Ja
Auto-negotiation
Ja
VLAN=ondersteuning
Ja
Aantal VLANs
4094

Data-uitwisseling

Switchingcapaciteit*
16 Gbit/s
MAC-adrestabel*
8000 entries
Aantal wachtrijen
8
Jumbo Frames ondersteuning
Ja
Jumbo frames
9000
Packet buffergeheugen
0,5 MB

Beveiliging

DHCP-functies
DHCP client, DHCP relay, DHCP snooping, DHCPv6 server, DHCPv6 snooping
IGMP snooping
Ja
Ondersteunde beveiligingsalgoritmen
802.1x RADIUS
MAC adres filtering
Ja
Authenticatie
MAC-gebaseerde authenticatie, Webgebaseerde authenticatie

Beveiliging

Authenticatie type
RADIUS

Multicast-functies

Multicast-ondersteuning
Ja

Protocollen

Beheerprotocollen
SNMPv1/v2c/v3
IPv4- & IPv6-functies
IPv6 Telnet, IPv6 ping, IPv6 tracert

Design

Rack-montage*
Ja
Kleur van het product
Zwart
LED-indicatoren
Ja
Certificering
CE, FCC, RoHS

Prestatie

Fanloos
Ja

Energie

Vermogenstoevoer inclusief*
Ja

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Aantal Power over Ethernet plus (PoE +)-poorten
4

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 90 procent

Gewicht en omvang

Breedte
209 mm
Diepte
126 mm
Hoogte
26 mm

Verpakking

Gebruikershandleiding
Ja
Type verpakking
Doos

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
