V7 UPS1RM2U3000-1E UPS Line-interactive 3 kVA 2700 W

V7 UPS1RM2U3000-1E, Line-interactive, 3 kVA, 2700 W, Sinus, 720 J, 4 ms

Ruim op voorraad

Fabrikant V7
MPN UPS1RM2U3000-1E
EAN 0662919095234
€ 676,00 excl. BTW

V7 UPS1RM2U3000-1E UPS Line-interactive 3 kVA 2700 W

Go big with the 3000VA Rack Mount UPS from V7, our most powerful UPS. This Rack Mount UPS provides a backup power source for mission critical equipment in server rooms, data centers, and other vital equipment. It ensures a consistent flow of electricity to help prevent equipment failure and data loss during power failures, brownouts, or other power issues that can occur with power in your building. The USB port allows built in UPS configuration and control, and auto-shutdown features for your computers or servers.

- 3000VA Rack Mount UPS with Pure Sine Wave Output with 8 IEC Outlets
- Boost and Buck AVR automatically adjusts for under-voltage and over-voltage ensuring stable power and longer life batteries.
- ECO (Efficiency Corrective Optimizer) for energy saving and EPO function (Emergency Power Off)
- Programmable power management outlets maximize backup time to critical devices by setting shorter backup time for non-critical devices
- Audio & Visual alarms for immediate warning of battery, load, and other issues

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

UPS-topologie*
Line-interactive
Output power capacity*
3 kVA
Uitgangsvermogen*
2700 W
Golfvorm*
Sinus
Surge energy rating
720 J
Contacttijd (min)
4 ms
Contacttijd (max)
8 ms
Emergency Power Off (EPO)
Ja
Geluidsniveau
45 dB
Spanningsbeveiliging
Ja
Geluidsalarm(en)
Ja
Hoorbare alarmstanden
Alarm bij werking op batterij, Storing, Alarm bij laag batterijniveau, Alarm bij overbelasting
Land van herkomst
China

Poorten & interfaces

Stopcontacttypes
IEC Jumpers
Number of output IEC jumpers
8
USB-poort
Ja
Aantal USB 2.0-poorten
1
Seriële interface
Ja
Soort serieële aansluiting
RS-232
RS-232 port
1
Modem (RJ-11) poort
1
Aantal Ethernet LAN (RJ-45)-poorten
1
Noodstop-aansluiting (EPO)
Ja

Accu/Batterij

Batterijtechnologie
Sealed Lead Acid (VRLA)
Batterij capaciteit
9 Ah
Batterij capaciteit
648 VAh
Accu/Batterij voltage
12 V
Typische backup tijd op volledige lading
3,7 min
Typische backup tijd op halve lading
11,8 min

Accu/Batterij

Accu/Batterij oplaadtijd
4 uur

Design

Vormfactor*
Rackmontage/toren
Rackcapaciteit
2U
Snoerlengte
3,05 m
Type koeling
Actief
Kleur van het product*
Zwart
Type beeldscherm
LCD
LED-indicatoren
Ja
Certificering
CE, REACH

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 90 procent

Technische details

Duurzaamheidscertificaten
RoHS

Gewicht en omvang

Breedte
438 mm
Diepte
630 mm
Hoogte
88 mm
Gewicht
29,3 kg
Breedte verpakking
565 mm
Diepte verpakking
700 mm
Hoogte verpakking
240 mm
Gewicht verpakking
32,6 kg

Verpakking

Snelle installatiehandleiding
Ja
Garantiekaart
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85078000
