Vertiv Liebert GXE3-10KIRT5UXL UPS Dubbele conversie (online) 10 kVA 10000 W

Vertiv Liebert GXE3-10KIRT5UXL, Dubbele conversie (online), 10 kVA, 10000 W, Zuivere sinus, 178 V, 288 V

Niet op voorraad

Fabrikant Vertiv
MPN GXE3-10KIRT5UXL
EAN 0767041034844
€ 3.832,00 excl. BTW

Vertiv Liebert GXE3-10KIRT5UXL UPS Dubbele conversie (online) 10 kVA 10000 W

The Vertiv Liebert GXE UPS is an affordable, efficient UPS designed for delivering best-in-class power protection to equipment at the edge of networks or in remote sites. This 10000 VA UPS offers online double conversion solution. Its unity output power factor (1.0) enables continuous and reliable power to more connected devices. The high efficiency in both online and ECO modes of operation (up to 98% in ECO mode) for this already affordable UPS further drives energy and operational costs savings. Additional external battery cabinets provide scalable runtime for those applications requiring longer period of backup in case of AC mains failures. This single-phase UPS can be mounted as a tower or placed inside a rack cabinet, with a gravity sensing LCD display to allow rack/tower configurations. It has remote management capability with optional network management cards. With proven reliability, it is ideal for critical applications in financial, government, and manufacturing industries.
  • Reliable double-conversion online topology with zero transfer time
  • Unity output power factor (1.0) to protect more loads
  • Hot-swappable user replaceable batteries
  • Remote management and server shutdown with the optional network management card
  • Fast recharge time (3 hours at 90%) and scalable runtime capabilities

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

UPS-topologie*
Dubbele conversie (online)
Output power capacity*
10 kVA
Uitgangsvermogen*
10000 W
Golfvorm*
Zuivere sinus
Ingang operation voltage (min)*
178 V
Ingang operation voltage (max)*
288 V
Frequentie*
40/70 Hz
Uitgang operation voltage (min)
220 V
Uitgang operation voltage (max)
230 V
Surge energy rating
600 J
Efficiëntie (On-line modus)
94 procent
Efficiëntie (ECO-modus)
98 procent
Emergency Power Off (EPO)
Ja
EMI/RFI geluidsfiltering
Ja
EMI/RFI ruisverzwakking
58 dB
Stroomspanning bescherming
Overbelasting
Geluidsalarm(en)
Ja
Land van herkomst
China

Poorten & interfaces

USB-poort
Ja

Accu/Batterij

Batterijtechnologie
Sealed Lead Acid (VRLA)
Acculevensduur (max)
5 jaar

Design

Vormfactor*
Tower
Rackcapaciteit
5U

Design

Kleur van het product*
Zwart
Type beeldscherm
LCD
Certificering
CE, UKCA, Morocco, RCM, CB report, EAC

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-20 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent

Technische details

Duurzaamheidscertificaten
REACH, RoHS, WEEE

Gewicht en omvang

Breedte
430 mm
Diepte
700 mm
Hoogte
217 mm
Gewicht
80 kg
Breedte verpakking
600 mm
Diepte verpakking
800 mm
Hoogte verpakking
530 mm
Gewicht verpakking
102 kg

Verpakking

Rekbevestigingspakket
Ja
Meegeleverde kabels
USB-kabel
Snelle installatiehandleiding
Ja

Overige specificaties

Nominale input voltage
230 V
