Viewsonic CDE5530 beeldkrant Digitale signage flatscreen 139,7 cm (55") LCD 450 cd/m² 4K Ultra HD Zwart Type processor Android 11 24/7

Viewsonic CDE5530, Digitale signage flatscreen, 139,7 cm (55"), LCD, 3840 x 2160 Pixels, 24/7

Ruim op voorraad (levering verwacht binnen 3 dagen)

Fabrikant ViewSonic
MPN CDE5530
EAN 0766907017472
€ 838,00 excl. BTW

Viewsonic CDE5530 beeldkrant Digitale signage flatscreen 139,7 cm (55") LCD 450 cd/m² 4K Ultra HD Zwart Type processor Android 11 24/7

The ViewSonic® CDE5520 is a 55” premium 4K large format presentation display. With features including a razor-sharp resolution of 3840 x 2160, 450-nit high brightness, 178-degree ultra-wide viewing angles, 2 x 10W speakers, and wireless screen sharing, the display transforms meeting rooms into dynamic communications hubs. The built-in ViewBoard® screen sharing software*, ViewBoard® Cast (along with the optional ViewSonic® vCastSender app), enables both on-site and online users to participate in conferences and simultaneously share content. Equipped with twin dual-core processors, 3GB RAM, and 16GB of internal memory, the CDE5520 can play multimedia from internal storage or a USB flash drive. And with remote configuration and content management system support, the ViewSonic® CDE5520 is also suitable for a wide array of diverse signage applications. *Chrome, Android, Windows, Mac OS, and iOS compliant

Multiple Ways to Connect and Share

Connect wirelessly through your network or directly to the display. Use the ViewBoard Cast™ screen sharing software along with the web-based myViewBoard® Display app to allow up to four participants (on-site and remote) to connect and share their content regardless of what OS platform they are using (Windows, MacOS, Chrome OS, Android, iOS). In addition, AirPlay, Miracast and the optional ViewBoard Cast button all offer wireless and software-less casting options.

AV Control System Interoperability

These displays are Crestron Connected® as well as Extron and AMX certified for seamless integration. Network admins are always in control with the ability to send control signals such as on/off, switch inputs, push firmware and security updates, and get status from the display.

Centralized Device Control Manager

For IT admins, it’s tough managing the hundreds of devices and displays that live on the network. Now with myViewBoard Manager, an easy-to-use web-based application, IT can securely set up, manage and maintain all of the displays from a centralized dashboard.

Reliable 24/7 Operation Rating

Featuring a long lifespan, this professional-grade commercial display is designed for reliable use 24 hours a day, 7 days a week. Ideal in virtually any commercial application and environment, this commercial display delivers peace of mind with its robust and durable design.

Superb and Stunning Picture Quality

With 4K resolution, high brightness and 25% high haze anti-glare glass treatment, these displays deliver bright, clear and sharp images in any indoor environment.

Powerful Secured Embedded Platform

This display can execute several tasks at once while providing smooth content playback without the need for a PC or media player. The embedded SoC provides PC-like performance and power to run apps, while hardened custom Android OS firmware protects the display from viruses and security breaches by preventing unknown sources to be installed on the system.
  • Multiple Ways To Connect And Share Content
  • AV Control System Interoperability
  • Centralized Control Device Management
  • Reliable 24/7 Operation Rating
  • Superb And Stunning Picture Quality
  • Powerful Secured Embedded Platform

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beeldscherm

Soort paneel
ADS
LED backlight-type
Direct-LED
Beeldschermdiagonaal*
139,7 cm (55")
Display technologie*
LCD
Resolutie*
3840 x 2160 Pixels
Helderheid*
450 cd/m²
HD type*
4K Ultra HD
Touchscreen*
Nee
Oorspronkelijke beeldverhouding
16:9
Responstijd
8 ms
Typische contrastverhouding
1200:1
Contrast ratio (dynamisch)
5000:1
Kijkhoek, horizontaal
178°
Kijkhoek, verticaal
178°
Beeldscherm, aantal kleuren
1,07 miljard kleuren
Schermdiameter in centimeters
139 cm
Levensduur paneel
50000 uur
Systeemeigen vernieuwingsfrequentie
60 Hz
Waasniveau
25 procent
Hardheid oppervlak
3H

Poorten & interfaces

Aantal HDMI-poorten*
3
HDMI versie
2.1
Aantal HDMI-invoerpoorten
2
Aantal HDMI-uitvoerpoorten
1
DVI-poort*
Nee
USB-poort*
Ja
Aantal USB-aansluitingen
3
USB-versie
2.0/3.2 Gen 1 (3.1 Gen 1)
USB-connectortype
USB Type-A, USB Type-C
Ethernet LAN*
Ja
Aantal Ethernet LAN (RJ-45)-poorten
1
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Wifi*
Nee
RS-232
Ja
OPS-modulesleuf
Ja

Audio

Ingebouwde luidsprekers*
Ja
Aantal ingebouwde luidsprekers
2
Gemiddeld vermogen
20 W

Design

Productontwerp*
Digitale signage flatscreen
Ondersteuning voor plaatsing*
Binnen
Model
Horizontaal/Verticaal
Kleur van het product*
Zwart
Beeldscherm vorm
Flat
VESA-montage*
Ja
Paneelmontage-interface
400 x 200 mm
Bezel breedte (onderkant)
1,5 cm
Bezel breedte (zijkant)
1,5 cm

Design

Bezel breedte (bovenkant)
1,5 cm
Antireflectiescherm
Ja
Montagewijze
Muur

Prestatie

Bedoeld voor*
Universeel
Bedrijfsuren (uren/dagen)
24/7
HDCP
Ja
HDCP versie
2.2

Energie

Stroomverbruik (typisch)*
155 W
Vermogensverbruik (max)
250 W
Stroomverbruik (in standby)*
0,5 W
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz

Computersysteem

Computersysteem*
Ja
Computersysteemtype
System-on-Chip (SoC)
Type processor*
Ja
Processormodel
Amlogic T982
Frequentie van processor
1,9 GHz
Aantal processorkernen
4
Intern geheugen
4 GB
On-board graphics adapter model
ARM Mali-G52
Interne opslagcapaciteit
32 GB
Inclusief besturingssysteem
Android 11

Gewicht en omvang

Schermbreedte
1233 mm
Display diepte
71,5 mm
Display hoogte
703,5 mm
Display gewicht
13,4 kg

Verpakking

Breedte verpakking
1332 mm
Diepte verpakking
156 mm
Hoogte verpakking
819 mm
Gewicht verpakking
19,5 kg

Inhoud van de verpakking

Afstandsbediening inbegrepen
Ja
Batterijen inbegrepen
Ja
Meegeleverde kabels
AC, HDMI, RS-232, USB Type-C
Montage gereedschap
Ja

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
20 - 80 procent

Certificaten

Certificering
cTUus, FCC, Energy Star 8.0, RoHS, Mexico NOM, Mexico Energy

Technische details

OPS-slot
1

Overige specificaties

Snelstartgids
Ja
